Overview

The new 8280 TTV is a reliable, powerful and fully connected working machine with the perfect technology mix for professional farmers and contractors. It sets new standards in terms of operator’s comfort, acceleration on the road and dynamic driving behavior.

Thanks to the powerful DEUTZ TTCD 6.1 double turbocharged engine the tractor generates more power already at lower rpms. And due to the light vehicle weight between 9,5 and 10,3 tonnes an unrivalled power density of 73 lbs/hp is reached. The high maximum permissible weight of 16 tons, available @ 32 mph, also allows up to 6.5 tons payload, which sets the benchmark in this cluster. Due to a wide offering of specifications, the 8280 TTV can be customized on all applications and adapted precisely to the customer’s requirements: from open field to transport, grassland operations to all heavy field or industry requirements. The 8280 TTV is also the perfect all-round tractor for modern contractors. The new design features introduced for the cabin ensure an unprecedented level of comfort, creating the ideal working environment for long hours behind the wheel. The new smart farming technologies like SDF Fleet Management or the SR20 receiver make the 8280 TTV the tractor for the future.

Cab/Operations

Maximum support for the driver.

The new 8280 TTV is a working machine with a great level of comfort even on demanding jobs. Pneumatic cab suspension, computerized analysis of airflows, the use of high-quality materials and the spaciousness of the cab of the new 8280 TTV create an inviting, comfortable and productive working environment. The ergonomic design of the controls, the logical layout and the clearly presented information make driving the tractor that much easier and safer. The cab is detached from the new designed bonnet, which keeps the heat, vibrations and noise out.

Maximum support for the driver.

The new 8280 TTV is a working machine with a great level of comfort even on demanding jobs. Pneumatic cab suspension, computerized analysis of airflows, the use of high-quality materials and the spaciousness of the cab of the new 8280 TTV create an inviting, comfortable and productive working environment. The ergonomic design of the controls, the logical layout and the clearly presented information make driving the tractor that much easier and safer. The cab is detached from the new designed bonnet, which keeps the heat, vibrations and noise out of the cab and raises the driver’s comfort on a new high-class level.

Cab/Operations
iMONITOR3.
ISOBUS

DAB+ radio with hands-free and bluetooth

USB smartphone charger

Smartphone phone holder

Tablet rail with RAM(R) socket

Automatic air conditioning with additional air-outlets

Bottle refridgiator

Comfort leather seat with active clima system and 22° swivel

Fully adjustable MaxCom Armrest

Comfortable passenger leather seat

Pneumatic Cab suspension

The iMonitor is the fully integrated central user interface to control following functions:

Tractor settings

SDF Guidance

SDF Data Management

ISOBUS

Comfortip headland management

Up to 4 cameras

Xtend function


TRACTOR IMPLEMENT MANAGEMENT (TIM)

As first tractor producer on the market DEUTZ-FAHR has received the TIM certification. This allows a bi-directional. communication between tractor and implement. As a result, the implement can automatically control certain tractor functions. This includes: driving speed, hydraulic valves, hitch and PTO. TIM is the key element for higher efficiency, less fatigue and a better working result. Speak to your sales partner!

Engine

Double Turbo Charged.

The 8280 TTV is equipped with an all-new DEUTZ 6-cylinder engine with 6.1L capacity and double turbocharger. It is designed for the maximum in performance and efficiency. The state-of-the-art common rail system meets the requirements of the EU Stage V and the injection pump is lubricated by oil – working with a high injection pressure of 29,008 psi that optimizes the combustion of fuel and Ad-Blue and guarantees a reactive and dynamic engine behaviour. Thus, the well-rounded torque curve ensures high power reserves at lower engine speeds.

Tractor Model9340
EngineDeutz TTCD 7.8 L06
Rated / Max. Horsepower 316 / 336
Cylinder Displacement 7.8 liter 6-cylinder
Common Rail Fuel Pressure29,000 PSI
RPM at Rated / Max. Power 2100 / 1900
Max. Torque 1011 lb-ft @ 1500 RPM
Fuel Capacity158 gallons
DEF (AdBlue) Capacity14.5 gallons

Find More Information

Find More Information

Find More Information

Hydraulics

Variable Hydraulics
Rising the productivity.

With a maximum lifting capacity in the rear of up to 24,471 lbs, the 8280 TTV has the power to lift a wide range of implements. To guarantee the maximum versatility of hydraulics, the new 8280 TTV is available in different configurations, all with electronic valves with up to 55 gal/min throughput. There are up to five hydraulic control valves, on the rear side, while the front area is equipped with up to two. The highlight: all valves can be controlled proportionally. The operation of the 8th spool valve is located on the small joystick and can be precisely used for combined maneuvers with the cross lever.

Hydraulics shortcode

Want to know more?

Find more information about the 8280 TTV
8 Series 8280 TTV
Full Brochure
Download Full
Brochure
Download
8 Series 8280 TTV
Spec Sheet
Download
Spec Sheet
Download
