Product Overview:

Series 5D Keyline


The Deutz-Fahr 5D Keyline is an embodies maneuverability with high capacities due to a robust design incorporating all you expect from a premium utility tractor. This robust tractor utilizes the proven FARMotion 2.9-liter engine, delivering a highly efficient 75 rated horsepower. This coupled with a standard 15x15 shuttle shift transmission enables you to select the right speed for your application.


State-of-the-art, displacement-optimised three-cylinder FARMotion engines with power output of 75 rated horsepower can be found under the hood of the new 5D Keyline series models (exhaust emissions standard Stage V). These engines have been specially developed for use in the agricultural industry. Electronic 2000 bar common-rail fuel injection with Turbo Intercooler aspiration guarantee high power delivery and a high torque with minimal fuel consumption and low emission values. The newly developed compact radiator with viscous-drive fans and PowerCore air cleaner promotes engine efficiency. The cooling system is also easily accessible, which significantly simplifies maintenance and cleaning work.


The Deutz-Fahr Series 5D Keyline provides operators with the flexibility and efficiency to succeed in the most challenging applications. The shuttle shift transmission proves extremely effective at aiding in loader applications, enabling operators to easily change direction. The 15x15 speed transmission with 5-spend synchronized main gear box enables greater flexibility within each range and the ability to have access to more speeds within a range.


The PTO utilizes proven designs and valuable features to provide value in all applications. The independent PTO utilizes a manual engagement handle, allowing for the operator to “feather” engagement when the application demands.


The Series 5D Keyline open center hydraulic system features 13.2 gallons per minute of hydraulic flow, split between two separate pumps. This Series features two standard rear remotes as standard equipment. The rear remote levers are conveniently located to the right of the operator, reducing operator fatigue during repetitive task such as round baling etc.


All new 5D Keyline series models come with all-wheel drive and wet disc brakes on all four wheels. A selector valve ensures that the braking force is distributed across the individual wheels. When both brake pedals are depressed, all four wheels are braked. When the left-hand pedal is depressed, the rear-left wheel is braked. When the right-hand pedal is depressed, the rear-right wheel is braked. This provides maximum safety in all situations. A hydraulic trailer brake is available on request (country-specific). The front axle was developed by DEUTZ-FAHR specially for this horsepower class. The four-wheel drive system and 100% differential lock can be electrohydraulically operated at the touch of a button. The 55° steering angle guarantees maximum manoeuvrability.


Anyone climbing into the 5D Keyline series will immediately get the sense that it is a great place to work. Wide doors, a bright and welcoming atmosphere, plus 360° all-round visibility help farmers work efficiently. As is standard with DEUTZ-FAHR, all controls are logically arranged according to the frequency with which they are used, placed within easy reach and colour-coded. The instrument cluster in the adjustable steering column provides the driver with continuous information regarding all operating statuses. Highly sought visibility roof panel provides unobstructed view above the cab, extremely useful in loader applications to improve efficiency and safety. Additionally, a large cabin and standard instructor seat provide the ability to have an instructor in the cab with the primary operator.
